45N1043 Battery for Lenovo ThinkPad Edge E530 E430 E540 E440 | 11.1V 5200mAh 58Wh

Detailed Product Specifications and Features:

Core Technical Parameters:

Property	Specification
Model Numbers	45N1043 (ThinkPad 75+) / 45N1042
Battery Type	Li-ion (Grade A+ High-Capacity Cells)
Voltage	11.1V (Fully compatible with 10.8V)
Capacity	5200mAh / 58Wh
Cells	6-Cell
Condition	100% Brand New from Factory
Life Cycle	600 - 1000 recharge cycles
Multiple Protection	Over Current, Over Voltage, Over Charge & Discharge, Overheat, Short Circuit, ESD, EMI
Color	Black
Certifications	UL2054, CE, FCC, RoHS, UN38.3, MSDS, IEC62133
OEM/ODM	Yes(Accepted)
Warranty	18 Months After Sales, 24/7 Email Support.
Product Dimensions	12.13 x 3.7 x 1.77 inches
Item Weight	12 ounces



Technical Note:

The 45N1043 (ThinkPad 75+) is an External Removable battery. It features an advanced authentication chip to ensure 100% compatibility with Lenovo Power Manager and fast-charging protocols. This 11.1V 58Wh version offers superior energy density compared to standard 4400mAh alternatives.



Product Features:

• Battery Newest Premium Grade Cells
• Best Circuit Board
• Multiple command chip control, keep the battery stable charge and discharge;
• Over-charger protection and discharger protection, short-circuit protection, ensure fast charges and low power consumption
• Easy & Quick Installation
• Our battery is 100% compatible with the original battery and meets
• CE/FCC/ROHS/UL-certified standards. It is 100% new from the manufacturer and can support up to 1000 recharge cycles over the life of the battery
• Power Interface: Gold-plated connector points to ensure current transport excellently and serve stably.
• Enclosure: The enclosure is made of ABS + PC high-quality material, which has a high-temperature-resistant function to protect your laptop from overheating
• Battery Buckle: The battery buckle is closely connected to the laptop, and the metal interface is stably powered

45N1043 (ThinkPad 75+) / 45N1042 Battery Compatibility Laptop Model List:

Series	Specific Laptop Models & Machine Type-Models (MTM)
ThinkPad Edge	Edge E430 / E430c / E431 / E435: (Type 3254, 6271, 6883, 20B8, 20B7, 3254-CTO, 6271-23U) Edge E440 / E445: (Type 20C5, 20BA, 20C5004YUS, 20C50050US) Edge E530 / E530c / E531 / E535: (Type 3259, 6272, 6885, 6887, 20B9, 20BA, 3259-CTO, 6272-27U) Edge E540 / E545: (Type 20C6, 20B2, 20C6008RUS, 20C6008SUS)
Lenovo G Series	G580 / G585 / G580A: (Type 2189, 2689, 20150, 20157, 5934, 5935, 59344050, 59344054) G480 / G485 / G480A: (Type 2184, 20149, 20156) G500 / G505 / G510: (Type 20236, 20238, 20240, 20244) G400 / G405 / G410: (Type 20235, 20237, 20239)
Lenovo B Series	B580 / B585 / B580A: (Type 20144, 4359, 4363, 4366, 20144-CTO) B590 / B595 / B590A: (Type 20206, 20208, 3761, 6274, 20206-5936, 20208-5937) B480 / B485 / B490 / B495: (Type 20140, 3772, 20205, 20207)
Lenovo V Series	V580 / V580c: (Type 20143, 20141, 20160, 4361) V480 / V480c / V480s: (Type 20142, 20159, 4358)
Sub-Suffixes	-ITH (i3), -IFI (i5), -ISE (i7), -ARE, -AST, -ASW, -BNI, -BEI



L15M4PC2 / L15L4PC2 / L15C4PC2 Battery Compatible P/N (Part Numbers) List (FRU / ASM / P/N):

• ThinkPad 75+ (6-Cell) | ThinkPad 75++ (9-Cell)
• FRU P/N: 45N1043, 45N1042, 45N1048, 45N1049, 45N1051, 45N1053, 45N1055, 45N1045, 45N1047, 45N1184, 45N1185
• ASM P/N: 45N1044, 45N1050, 45N1052, 45N1054
• Marketing P/N: 0A36311 (75+), 0A36312 (75++)
• Lenovo Consumer P/N: L11L6Y01, L11M6Y01, L11N6Y01, L11P6Y01, L11S6Y01, L11L6F01, L11S6F01
• ID Code: 121500047, 121500049, 121500052, 121500053

Why Choose HTJ 45N1043 58Wh Battery?

• True 58Wh High-Capacity Performance:
  Many standard replacements only offer 4400mAh (48Wh). The HTJ 45N1043 is engineered with high-density Grade A+ cells to deliver a full 5200mAh (58Wh). This 11.1V  X 5200mAh configuration provides roughly 20% more runtime for your ThinkPad Edge.

• Full Authentication Chip Support:
  Modern Lenovo laptops are picky about batteries. HTJ batteries include an updated intelligent chip that bypasses “Non-genuine battery” warnings, ensuring full compatibility with Lenovo Vantage software and optimized charging speeds.

• Precision Lock & Safety Fit:
  Built using 1:1 original industrial molds, our 45N1043 snaps into the ThinkPad E530 or G580 chassis with zero wiggle. This ensures consistent electrical contact and prevents the laptop from suddenly shutting down when moved.

• Industry-Leading 18-Month Warranty:
  HTJ provides a factory-direct 18-month warranty. Every battery undergoes strict 48-hour aging tests and multiple cycle validations to ensure you receive a reliable power source that lasts for years, not months.



How to Install Your New 45N1043 Battery

Replacing the external 45N1043 battery is a simple, tool-free process.

⚠️ Crucial Safety Preparation

• Shutdown: Power off your Lenovo laptop and unplug the AC adapter.
• Surface: Place the laptop upside down on a soft surface.

45N1043 Battery Step-by-Step Installation Guide

1. Locate the Latches: On the bottom of the laptop, you will see two sliding latches.
2. Unlock and Release: Slide the “Lock” latch to the open position. Then, slide and hold the “Release” latch while pulling the old battery away from the laptop.
3. Insert the HTJ Battery: Align the battery connectors and slide the new HTJ 45N1043 battery into the bay until it clicks into place.
4. Engage the Manual Lock: Important: Slide the lock latch back to the “Closed” position to secure the battery.
5. Initialization: Plug in the charger. Charge the battery to 100% without interruption. For the first two uses, let it discharge to 5% to calibrate the Windows battery gauge.

💡 Pro Tip:

If you have a ThinkPad E530 or G580 that is used primarily as a desktop replacement (plugged in 24/7), we recommend using Lenovo Vantage to set a “Battery Charge Threshold” (e.g., stopping at 80%). This significantly extends the chemical life of your new 45N1043 cells.



FAQ (Frequently Asked Questions)

Q: Will this 11.1V battery work if my original was 10.8V?
A: Yes. 10.8V and 11.1V are fully interchangeable for this laptop series. They both represent the same internal cell architecture.

Q: Does this battery fit the G580 model?
A: Yes. The G580 uses the L11S6Y01 battery, which is the consumer-market equivalent of the 45N1043. They are 100% compatible.

Q: My laptop says “Battery not authorized.” What should I do?
A: Ensure the battery is fully pushed in and the lock latch is engaged. HTJ batteries are designed to bypass this, but a loose connection can sometimes trigger the warning.



Laptop Maintenance Tips:

1. New battery: For using a new battery, you’d better try a few cycles of discharging to 5%. then charging up to 95%. So that it can be activated completely
2. Overuse: Do not always run out of a battery to 0%, as this would shorten its usage life.
3. Charging sequence: When charging, first install the battery, then turn on the power. When fully charged, first cut off the power, then pull the power plug.
4. Long-term storage: Please store the unused battery fully charged. (Charge it once a month.) Do not store at low power to prevent reducing the lifespan of a battery
5. Charger: Do not replace the laptop adapter casually. If the original adapter cannot be applied due to malfunction or damage, please replace the models so as not to reduce the service life of the battery due to incompatibility.
