L12S4E01 Battery for Lenovo G400s G500s G50-70 G50-80 Z710 | 14.8V 2600mAh 38Wh

Detailed Product Specifications and Features:

Core Technical Parameters:

Property	Specification
Model Numbers	45N1127 (ThinkPad 68+) / 45N1125 (ThinkPad 68)
Battery Type	Li-ion (High-Density Grade A+ Cells)
Voltage	10.8V (Fully compatible with 11.1V / 11.22V)
Capacity	5200mAh / 56Wh (Extended High-Capacity 6-Cell)
Cells	6-Cell
Condition	100% Brand New from Factory
Life Cycle	600 - 1000 recharge cycles
Multiple Protection	Over Current, Over Voltage, Over Charge & Discharge, Overheat, Short Circuit, ESD, EMI
Color	Black
Certifications	UL2054, CE, FCC, RoHS, UN38.3, MSDS, IEC62133
OEM/ODM	Yes(Accepted)
Warranty	18 Months After Sales, 24/7 Email Support.
Product Dimensions	9.92 x 3.43 x 1.61 inches
Item Weight	7.8 ounces

Technical Note:

Design Note: The 45N1127 (ThinkPad 68+) is a high-capacity external rear battery. It integrates perfectly with Lenovo’s “Power Bridge” technology, allowing for hot-swapping if an internal battery is present.
Physical Note: As a 56Wh 6-cell extended pack, this battery is physically thicker than the standard 3-cell battery. It provides an ergonomic tilt to the chassis, improving typing comfort and enhancing airflow for better thermal management.

Product Features:

• Battery Newest Premium Grade Cells
• Best Circuit Board
• Multiple command chip control, keep the battery stable charge and discharge;
• Over-charger protection and discharger protection, short-circuit protection, ensure fast charges and low power consumption
• Easy & Quick Installation
• Our battery is 100% compatible with the original battery and meets
• CE/FCC/ROHS/UL-certified standards. It is 100% new from the manufacturer and can support up to 1000 recharge cycles over the life of the battery
• Power Interface: Gold-plated connector points to ensure current transport excellently and serve stably.
• Enclosure: The enclosure is made of ABS + PC high-quality material, which has a high temperature-resistant function to protect your laptop from overheating
• Battery Buckle: The battery buckle is closely connected to the laptop, and the metal interface is stably powered

45N1127 (ThinkPad 68+) / 45N1125 (ThinkPad 68) Battery Compatibility Laptop Model List:

Series	Specific Laptop Models & Machine Types (MT / MTM)
ThinkPad T Series	ThinkPad T440 / T440s: (Type 20B6, 20B7, 20AL, 20AM) ThinkPad T450 / T450s: (Type 20BV, 20BW, 20DJ) ThinkPad T460: (Type 20FN, 20FM) [Not for T460s/T460p]
ThinkPad X Series	ThinkPad X240: (Type 20AL, 20AM) ThinkPad X250: (Type 20CL, 20CM) ThinkPad X260: (Type 20F5, 20F6) ThinkPad X270: (Type 20HM, 20HN, 20K5, 20K6)
ThinkPad L Series	ThinkPad L450: (Type 20DT, 20DU) ThinkPad L460: (Type 20JU, 20JV) ThinkPad L470: (Type 20J4, 20J5)
ThinkPad W/P Series	ThinkPad W550s: (Type 20E1, 20E2) ThinkPad P50s: (Type 20FK, 20FL)
Specific Suffixes	20B7000KUS, 20BV0006US, 20F50000US, 20ALCTO1WW, 20BW000BUS

45N1127 (ThinkPad 68+) / 45N1125 (ThinkPad 68) Battery Compatible P/N (Part Numbers) List:

FRU (Field Replaceable Unit) Numbers:

• • 45N1127 (56Wh/48Wh 68+)
  • 45N1125, 45N1124 (24Wh 68)
  • 45N1126, 45N1128, 45N1129, 45N1132
  • 45N1734, 45N1737, 45N1133, 45N1137
  • 01AV405, 01AV406, 01AV407, 01AV408 (X260/X270 Era FRUs)

ASM (Assembly) Numbers:

• • 45N1126, 45N1132, SB10K97576
  • SB10K97577, SB10K97578, SB10K97580
  • 121500146, 121500147, 121500148

Marketing / Option P/N:

• • ThinkPad Battery 68+ (0C52862)
  • ThinkPad Battery 68 (0C52861)

Why Choose HTJ 45N1127 56Wh Battery?

• High-Density 56Wh Capacity:
  Engineered for endurance, our 56Wh version provides 16% more power than standard 48Wh 6-cell batteries. This ensures a full day of productivity without searching for an outlet.
• Seamless Power Bridge Integration:
  HTJ batteries are fully compatible with Lenovo’s hot-swap logic. The system identifies it as “Battery 2,” draining it first so you can swap batteries while the laptop remains running.
• Grade A+ Cells & Advanced BMS:
  Equipped with premium lithium-ion cells and a sophisticated Battery Management System (BMS), our 45N1127 prevents common “unauthorized battery” errors and ensures stable voltage output.
• Premium 18-Month Factory Warranty:
  As a direct manufacturer, we back our 56Wh cells with a market-leading 18-month warranty. Every unit is tested for capacity consistency and thermal safety.



How to Install Your New 45N1127 Battery？

Replacing the external 45N1127 (68+) is a tool-free process using Lenovo’s dual-latch external system.

⚠️ Crucial Safety Preparation:

• Hot-Swap Support: If your internal battery (Battery 1) is functional, you do NOT need to shut down the laptop.
• Surface: Place the laptop upside down on a soft, clean surface to protect the screen lid.

45N1127 Battery Step-by-Step Installation Guide:

1. Locate the Dual Latches: Find the two sliding latches on the rear underside of the laptop.
2. Unlock the Manual Latch: Slide the right-side latch to the “Unlocked” position (red indicator will show).
3. Release the Spring Latch: Slide and hold the left-side spring-loaded release latch.
4. Remove the Old Battery: While holding the release latch, pull the old battery away from the chassis.
5. Insert the HTJ Battery: Align the guide rails of the new HTJ 45N1127 and slide it into the bay until it clicks.
6. Secure the Lock: Important: Slide the manual lock latch back to the “Locked” position.
7. Verification: Check the taskbar; “Battery 2” should now show as charging or healthy.

💡 Pro Tip:

To maximize the chemical life of your 5200mAh cells, use “Battery Charge Threshold” in Lenovo Vantage to stop charging at 80% if you are frequently using a docking station.

FAQ (Frequently Asked Questions)

Q: Is this 45N1127 battery compatible with old IBM ThinkPad laptops?
A: No. This battery is designed exclusively for Lenovo-era ThinkPad models (T440-T460, X240-X270). It will not fit legacy IBM systems produced before 2005.

Q: Can I use this on a ThinkPad T460s?
A: No. The “s” suffix models like the T460s use internal-only batteries. The 45N1127 fits the standard T460, T450s, and T440s, but NOT the T460s.

Q: My current battery is 24Wh (68). Will this 56Wh (68+) version work?
A: Yes, perfectly. They share the same connector. This version provides double the runtime but will protrude slightly from the bottom of the laptop.

Laptop Maintenance Tips:

1. New battery: For using a new battery, you’d better try a few cycles of discharging to 5%. then charging up to 95%. So that it can be activated completely
2. Overuse: Do not always run a battery down to 0%, as this would shorten its usage life.
3. Charging sequence: When charging, first install the battery, then turn on the power. When fully charged, first cut off the power, then pull the power plug.
4. Long-term storage: Please store the unused battery fully charged. (Charge it once a month.) Do not store at low power to prevent reducing the lifespan of a battery
5. Charger: Do not replace the laptop adapter casually. If the original adapter cannot be applied due to malfunction or damage, please replace the models so as not to reduce the service life of the battery due to incompatibility.
